Aircraft Potable water service truck adopts Qingling chassis converted into a new type of airport special vehicle for refilling water for aircraft, the product chassis cab for the flat head, single row seat, two-door type, crew of 3 people; drive type is 4 × 2, water tank volume is 4m³.
Elevated work platform is a working platform, the range of platform elevation is 400-3000, which can meet the working height of all existing aircraft. The lifting cylinder is a single-section hydraulic cylinder, and the lifting mechanism is made of new aluminum alloy profile. The platform is equipped with an electrical control switch assembly for controlling the pumping of water and the lifting and lowering of the platform, and is equipped with a nighttime operating light to facilitate night work.
The platform is equipped with safety protection device. When the hydraulic operating system fails to work, press the red “emergency stop” button to cut off the power of the engine and stop the operation immediately, the hydraulic system does not work, the platform can not continue to rise or fall, to avoid the accident of hitting the airplane.
The platform is equipped with a travel switch, when the platform is completely lowered to the lowest and touches the platform below the travel switch, the vehicle can only be driven, so as to ensure the safety of the operator, the platform is equipped with an emergency valve, when the oil pump motor failure, you can still make the lifting platform from the high place down.
Aircraft Potable water service truck Technical parameters
Overall dimensions (L×W×H) (mm): 6965×2300×2250
Minimum ground clearance mm: 215
Outer diameter of channel circle mm: 15500
Overall mass kg : 4650
Maximum speed km/h: 90
Fresh water tank volume L: 5800
Water supply flow rate L/min: 220
Temperature range ℃ ：-40~67
Fresh water tank material/thickness mm ：316L/5
Platform lifting range mm : 400~3000
Range km： 310
Water supply pressure Mpa: 0.25～0.35
Rated power/speed kw/r/min: 75/2000
Input voltage VDC：540
Rated output voltage VAC: 220
