Customer Requirement Passenger Stairs Chinese Origin

TY-KT58 Passenger stairs adopt self-made chassis, is equipped with advance electric system, the platform own two set of safety device of docking aircraft and height display circuit, its range of lifting height is 2400-5800mm. Please rest assured of stable supply and best after-sale service. As for after-sale service, if there is any problem when u purchase our product, please be confident of our good service. we will solve the problem well for u.
Availability:
Product Description



1. Product Profile:



TY-KT58 Passenger stairs adopt self-made chassis, is equipped with advance electric system, the platform own two set of safety device of docking aircraft and height display circuit, its range of lifting height is 2400-5800mm.

It is applicable for A300,A310, ,A320, A330, A340, B737, B747, B757, B767, B787,.etc.


2. Product Standard

1)MH/T6029-2014 《Passenger boarding ladder》

2)IATA AHM 920 《Function for loading stairs》

3)IATA AHM 923 《Function specs for lifting loading stairs》

4)GB/T 23422-2009 《Functional requirement of self–propelled passenger loading》


3. Main Configuration



Chassis: self-made chassis(choose RHD)

Engine type: 1. Deutz TCD3.6/74.4/Eur IV, Allison 1000 transmission

2. Cummins QSF3.8/73.8KW/ Eur IV, Okamura Y43250E transmission

3.Kohler KDI2504TCR/55KW/ Eur IV, Okamura Y43250E transmission

Ladder steps: Non-slip aluminum

Electric and hydraulic system: imported brand

Monitoring system: car backing radar with GPS/WIFI

Canopy: semi-closed or full-closed

Insulated device: 1. Diesel heating system; 2. Engine coolant heating device(220V);

20221020104458b368ad6cbbec47e8b47847a265d4f06e202210201045136c5e05dbccd44028845318b919b4dcf9


hope we can establish strategic business cooperation with your esteemed company.

4. Technical Parameter

Length mm

7600

width mm

2430

Height mm

3730

Wheelbase mm

3190

Wheelbase(front/rear) mm

2000/2000

Front overhang mm

1720

Rear overhang mm

1850

Front Protraction mm

90

Rear protraction mm

750

Approach Angle (°)

6

Departure angle (°)

5

Ramp angle(°)

10

Min Ground clearance mm

165

Turning clearance circle diameters mm

17500

GVW kg

9000

Max. speed km/h

45

Steps of Up-ladder

14

Ladder length mm

275

Steps of Down-ladder

13

Ladder width mm

1500

Max. inclined angle for ladder(°)

39.5

Height ladder mm

190

Operation height of ladder mm

2400~5800

Platform length mm

2840

Adjusting height

Telescopic

Platform width mm

2030
