Airport Self-Propelled Conveyor Belt Loader with fully enclosed cab

The cab frame of the Airport Self-Propelled Conveyor Belt Loader is made by welding steel plates and profiles. It is equipped with a sunshade and an electronic fan. The driver's seat is a movable one and is equipped with seat belts. The doors are connected to the cab by internal hinges. The periphery of the door frame is sealed with a rubber sealant, ensuring good sealing performance.

The front windshield of the cab is equipped with an electric wiper and a window washing device. Large combined mirrors are installed on both sides. The overall appearance is beautiful, the field of vision is wide, and it has good aerodynamic characteristics.

The cab assembly mainly consists of the instrument panel, steering assembly, wiper assembly and accessories.

Airport Self-Propelled  Conveyor Belt Loader Technical Parameters

Vehicle length mm :8240

Vehicle width mm :2000

Vehicle height mm :1600

Wheelbase mm :2900

Wheel distance front/rear mm :1730/1680

Approach Angle ° :12

Departure angle ° :20

Channel outer diameter mm :17000

Vehicle curb weight kg :3200

Front axle mass (unloaded) kg :1800

Rear axle mass (unloaded) kg :1400

Maximum speed km/h :30

Fuel Type :Diesel

Conveyor boom size length X width mm:8000 X 960

Conveyor Belt width mm :700

Conveyor Belt Working height mm :500-4200

Conveyor belt load capacity   kg/m:135
