Container cargo loader (diesel)

Container cargo loader (diesel) maximum loading weight of 15 tons of loader and can meet the all models of existing domestic airport main chamber set packing, container loading and unloading of goods

The overall structure of the container cargo loader (diesel) is composed of six parts: the front platform, the rear platform, the front fork frame, the rear fork frame, the front chassis and the rear chassis. They are welded in professional welding workshops, precision processing workshops, assembly workshops, etc., and have the advantages of high welding strength and high precision.

Technical parameters of container cargo loader (diesel)

Total length: 11,150mm

Total width :4410mm

Total height :3570mm

Engine rated power/speed :56 kW /2600r/min

Maximum torque/speed of the engine :375 N ·m /1600 r/min

Wheelbase: 1-2/2-3:3675/1050 mm

Track (front/rear):1965/3510mm

Approach Angle :3°

Departure Angle :3.5°

Minimum ground clearance :90mm

The outer diameter of the channel circle: 23,000mm

Curb weight: 23,300 kg

Transmission speed :0.3m/s

The maximum lifting capacity of the main platform is 15,000 kg

The main platform's lifting speed is 0.3m/s

The maximum lifting capacity of the bridge platform is 14,000 kg

Bridge platform lifting speed :0.11m/s

The lifting range of the main platform is 485 to 5640 mm

The lifting range of the bridge platform :1970-5640 mm

Maximum speed :14km/h

Guide rail width :3220mm
