Electric Air Catering Truck is an all-electric refrigeration unit independently developed by Tianyi. It adopts the inverter design of condensing fan, which can be reduced from 40° to 3° in 30 minutes and to 0° in 45 minutes. Using HFC404A environmentally friendly refrigerant, the product energy saving and environmental protection; The air conditioning compressor adopts the high efficiency horizontal DC inverter scroll compressor, which has the characteristics of low vibration and long service life.
The Electric Air Catering Truck is equipped with eight Performance indexes
Driving motor model :GC-TM1300-01
Travel motor controller model: GC-CU1300-01
Energy storage device assembly model: L228H01
Platform working height (mm) : 2550 ~ 6200
Body load rating (kg) : 6500
Front platform load rating (kg) : 3000
Front platform moving part load rating (kg) : 800
Adjustment range of the left and right parts of the front platform (mm) : 0 ~ 700
The expansion adjustment range of the moving part of the front platform (mm) : 0 ~ 600
Dimension of fixed part of front platform (L × W) (mm) : 2050x2265
Dimensions of the moving part of the front platform (L × W) (mm) : 950x1200
Quality (kg) : 13790
Overall dimensions (length × width × height) (mm) : 10500×2500×3700
driving range (km) : 440
Chassis model: QL1180BEVELQHY
External dimensions (length × width × height) (mm) : 7500×2500×2400
Front platform fixed part load rating (kg) : 2200
Total energy of energy storage device (kWh) : 281.92
