Electric Toilet Service Truck battery and drive motor

The battery of the electric Toilet Service Truck is made with the lithium iron phosphate battery from Guoxuan of Hefei. The entire vehicle is equipped with four battery boxes, with two on each side arranged in an upper-lower position. It is equipped with an automatic fire extinguishing device. Each battery box has a maintenance switch, which needs to be unplugged during maintenance or welding to prevent personal safety and equipment damage. It is equipped with an automatic fire extinguishing device.

Main parameters of the battery: Battery capacity: 162.28 Kwh, Cooling method: natural cooling, Protection level: IP67

Electric Toilet Service Truck drive motor

The drive motor is produced by Shanghai Electric Drive Co., Ltd. The main parameters of the motor are as follows: working temperature: -40 to +105, power: 60Kw, peak power: 110Kw, maximum speed: 4500rpm, cooling method: liquid cooling, protection level: IP67

Electric Toilet Service Truck Four-in-One Controller

The four-in-one controller is mainly a high-voltage integrated controller for the entire vehicle. It integrates the power supplies of multiple component systems into a single controller for centralized management, significantly enhancing the concentration of the controller and facilitating the layout of the entire vehicle. It mainly controls functions such as the drive motor, steering, power extraction from the upper part, DC/DC, etc. The protection level is: IP67.
