GPU180SP Ground Power Unit

GPU180SP Ground Power Unit equipped with a diesel engine that drives an AC brushless synchronous generator to produce 400Hz, 115V/200V AC three-phase four-wire power supply, and can output 28V DC power supply—suitable for aircraft ground power consumption and engine starting.

GPU180SP Ground Power Unit Main Technical Indicators

Overall Dimensions (mm):5900 × 1880 × 2300(L×W×H)

Weight(kg):5600

Noise Level (dB(A)):≤85

Fuel Type:Diesel

Rated Current (A):522

Rated Frequency (Hz):400

Rated Power Factor: 0.8

Overload Capacity:125%,5min;   150%,10s

Rated Power (kVA):180

Rated Voltage (V):115/200

Steady-State Voltage Range (V):112 to 120.5

Transient Voltage Range: Complies with MH/T 6019-2014 Standard

Rated Current (A) :800

5-Minute Overload Current (A) :1000

Rated Power (kW) :23

Rated Voltage (V): 28

Steady-State Voltage Range (V) :24 to 29.5

GPU180SP Ground Power Unit Technical Features

The upper assembly adopts a fully electronically controlled engine with precise rotational speed, meeting the non-road National III and Euro 3 emission standards

2. The upper structure adopts a brushless generator, which features low operating noise and high reliability

3. The operation interface is simple and clean, and the operation is easy

4. Perfect protection mechanisms: overspeed protection, low oil pressure protection, over-temperature protection, overvoltage and undervoltage protection, overfrequency and undervoltage protection, overcurrent protection, etc

The chassis adopts internationally renowned brands and meets the National VI emission standards
