Hluav taws xob Aircraft khib nyiab Truck Configuration V

Hluav taws xob Aircraft khib nyiab Truck configuration tsib technical parameters

Chassis: QL1100BEVEYKAY

Tsav Tsav: TZ370XS-LKM1201

Tsav Tsav Tsheb: KTZ54X38S-LKC1201

Hydraulic lub cev muaj zog: JSTY5060LJCE-1002002

Hydraulic Tsav Controller: JSTY5060LJCE-1002001

Lub zog cia khoom sib dhos: L150TX8

Tag nrho lub zog cia khoom hluav taws xob (kWh): 162.28

Platform ua haujlwm qhov siab (mm): 2400 ~ 5800

Qhov Loj (L × W × H) (mm): 7895 × 2340 × 3650

Kev kho ntau yam ntawm lub platform nthuav dav thiab kev cog lus (mm): 0 ~ 600 (luv luv) / 0 ~ 800 (ntev)

Rated load ntawm compartment (kg): 1900

Thawv ntim ntim (m3): 20

Lub kaum sab xis siab tshaj plaws ntawm lub compartment (°): 36.5

Qhov ceev tshaj plaws (km / h): 85

Ntev (km): 460

Zuag qhia tag nrho qhov zoo (kg): 7000

JSTY5060LJCE Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob tau hloov kho los ntawm Qingling QL1100BEVEYKAY chassis, uas tuaj yeem tuav cov khib nyiab ntawm ntau hom dav hlau xws li B737, B747, B777, B787, A320 series, A330, A350 thiab lwm yam. Lub tuam txhab ua ib feem kev hloov kho raws li cov khoom tsim. Nruab nyob rau hauv lub chassis: diesel tank, roj teeb, hydraulic valve pawg, hluav taws xob tswj lub thawv, hydraulic roj tank, hluav taws xob tua hluav taws, bracing taw, dej tso tsheb hlau luam, tail teeb thiab chassis los ua ke muaj pes tsawg leeg. Nyob rau hauv lub chassis ntawm pem hauv ntej thiab nram qab qhov chaw yog nruab nrog 4 ko taw, nyob rau hauv lub thawv nqa lub lag luam, yuav tsum tau muab tso rau hauv ob txhais ceg yuav tsum tau kom lub stability ntawm lub tsheb. Muaj 1 8Kg hluav taws tua hluav taws tau nruab rau sab nraum qab ntawm tus neeg caij tsheb chassis. Muaj 1 lub log thaiv kev txhawb nqa ntsia rau sab laug ntawm lub thawv.
