Ambulift Medical Lift It is widely applicable to the use of aircraft models such as A300, A310, A318, A319, A320, A330, A340, B707, B727, B737, B747, B757, B767, B777, DC8, 1L-18, 1L-62, MD11, and MD80, except for the Airbus A380.
The main features of the product are as follows:
(1) The chassis adopts Qingling Class II chassis, which has strong load-bearing capacity and good handling performance.
(2) The most scientific and reasonable fork frame structure, which adopts a large inclination Angle backpack-type oil cylinder.
(3) The upper and lower frame structure of the lifting device with a widened design has excellent stability.
(4) The hydraulic system adopts imported electromagnetic directional control valves, bidirectional hydraulic locks, emergency electric pumps, emergency manual pumps, etc. The oil cylinders are made of high-quality domestic products, and the key oil seals and vulnerable parts inside the oil cylinders are imported components.
(5) Complete emergency measures are in place to ensure the safety of passengers with mobility difficulties during the operation of the boarding vehicle.
(6) The electrical system is well designed with all kinds of functions complete, which can effectively prevent various misoperations and protect the equipment from damage.
(7) It adopts a combination control of integrated circuit boards and relays, making the control system advanced and reliable.
(8) A multi-layer progressive tail ladder is adopted, which is convenient for operators to get on and off the box body and is safe and reliable.
(9) Rich configuration options to meet the needs of different customers.
Main technical parameters of Ambulift Medical Lift
Driving motor model: TZ370XS-LKM1201
Controller model: VCU06
Battery model: L150TX8
Platform working height (mm) : 2200-6100
Rated load of the box body (kg) : 4000
Fixed platform rated load (kg) : 1700
Rated load of the movable platform (kg) : 1100
Platform telescopic adjustment range (mm) : 0-600
Fixed platform dimensions (length × width) (mm) : 2300×2000
Mobile platform dimensions (length × width) (mm) : 700×1960
Curb weight (kg) : 10,600
Wheelbase (mm) : 5200
Overall dimensions (length × width × height) (mm) : 9570×2400×3770
Maximum speed (km/h) : 85
Minimum ground clearance (mm) : 180
Range (km) : 340
Chassis model: QL1103BEVEYMAY
