JIANGSU TIANYI model TY-T120 is a kind of up-to-date developed type tow tractor with light capacity of towing the narrow body aircrafts as push back based on absorption of the similar equipment from local and overseas markets. The equipment has the features as below: Four wheel drive
Four wheel hydraulic steering
Four wheel hydraulic braking
Four Steering selection of modes: (front wheel steering, four wheel coordinated steering, and Crab wheel steering)
The complete equipment is tight constructed with low Centre of gravity and low height of total shape. The maximum towing capacity can be 150TON that makes it is able to provide towing service for the aircrafts such as B757, B737, B727, B717, A320, MD-90, MD82, TU154 and other narrow body or small size aircrafts.
Aircraft Tow Tractor Main Technical Parameters
o Max. Traction Value: 120KN
o Max. Towing capacity: 120T
o Gross weight : 12,000KG
o Overall dimension:
o Length (without towing assembly): 4800mm
(With towing assembly): 5360mm
o Width (with rear view mirror): 2100mm
o Height : 2020mm
o Wheelbase: 2150mm
o Ground Clearance: 200mm
o Turning Radius: 5800mm (two wheel) , 3400mm (four wheel)
o Max. Vehicle Speed: 25 Km/h
o Drive method: hydraulically mechanical transmission, double axle four wheel driving. o Braking: hydraulically, two-way, accumulator pressure maintaining
