Aircraft Refuse Receiving Vehicle (WTJ5060LJC) Technical Parameters

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Product standard
1)GB/T31029-2014 Aircraft Garbage Vehicle
2)AHM910 Basic Requirements for Aviation Ground Equipment
3)AHM913 Basic Safety Requirements for Aviation Ground Equipment
4)AHM915《Standard Control Devices
5)CCAR-137-CA-R3《Civil Airport Special Equipment Management Regulations
(6) AP-137-CA-2015-02 "Inspection Methods for Specialised Equipment for Civil Airports (for Trial Implementation)".
(7) GB3847-2005 "Vehicle Compression-ignition Engine and Compression-ignition Engine Vehicle Exhaust Smoke Emission Limits and Measurement Methods".
(8) GB20891-2014 "Emission Limits and Measurement Methods for Exhaust Pollutants of Diesel Engines Used in Non-Road Mobile Machinery (China Stage III and IV)".

Technical Parameters
Chassis: QL1070A5KAY
Engine: 4HK1CN5HS
Transmission: MSB-5SM
Overall length (mm): 7895
Overall width (mm): 2260
Overall height (mm): 3500
Wheelbase (mm): 3815
Wheelbase (front/rear) (mm): 1504/1425
Front overhang (mm): 1050
Rear Suspension (mm): 1370
Approach Angle (°): 24
Departure Angle (°): 12
Minimum Ground Clearance (mm): 180
Overall mass (kg): 5300
Gross mass (kg): 6510
Outer diameter of access circle (mm): 18000
Maximum travelling speed (km/h): 80
Trash compartment volume (m⊃3;):15.8
Maximum tipping angle of the compartment (°): 35
Minimum height of working platform (mm): 2400
Maximum height of working platform (mm): 5800
