7 Ton Cargo Loader

The 7T cargo Loader is a diesel vehicle with a loading capacity of 7,000 kg and a transport speed of 25 km/h. The chassis is based on a sturdy steel construction and reinforced to prevent damage and resist warping.
Availability:
Product Description

7 ton cargo loader

The 7T cargo Loader is a diesel vehicle with a loading capacity of 7,000 kg and a transport speed of 25 km/h. The chassis is based on a sturdy steel construction and reinforced to prevent damage and resist warping.

The device is specifically designed for transport of heavy and sensitive air freight. a cross between between a Cargo Loader and Dolly Train, these transporters notably increase the clearance capacity on large international airports.

The added technology for the drive is the first of its kind in aircraft handling equipment. This model has a closed hydraulic circuit with a diesel engine capacity that reduces fuel consumption and noise emission.

The improved cold starting feature is ideal for airports located in areas subject to harsh winters.

The device is designed both for Lower Deck and Main Deck handling. The high handling demands makes this model the perfect unit for passenger and freight aircrafts up to the Boeing 747


Technical Specifications

Guide rail operating width: 1,600 – 3,260 mm

Turning Radius : 8,500 mm

Weight:18.8 t

Transport Speed: 18 m/min

Lifting/Lowering Time: 15 – 22 sec.

Travel Speed: max. 15 km/h


Main Platform

Load bearing Capacity: 7,000 kg

Stroke height: 490 mm- 3,700mm


Bridge Platform

Load bearing Capacity: 7,000 kg

Stroke height: 1,850 - 3,700 mm


Design

Front Axle: steering axle with planetary gear

Rear Axle: non-driven

Tyres: front axle / rear axle Large-dimensioned air tyres / solid rubber tyres

Support :6 double-acting hydraulic cylinders

Motor: Deutz Diesel TD2011 M4 with EMR

Brake System: hydraulic multiple disc brake and spring-loaded parking brake.
