Electric Passenger Stairs (Low Voltage)

JSTY5080KTE passenger boarding ladder (electric)(hereinafter referred to as boarding ladder) is a new type of boarding ladder designed and developed by Jiangsu Tianyi Aviation Industry Co., LTD. The vehicle uses pure electric energy as the driving force, self-made chassis with upper and lower ladder body, movable side plate, diagonal lift device, platform assembly, front and rear legs, hydraulic system, electrical system and so on. The height of the flight ladder platform from the ground is 2400mm to 5900mm.
Availability:
Product Description

JSTY5080KTE passenger boarding ladder (electric)(hereinafter referred to as boarding ladder) is a new type of boarding ladder designed and developed by Jiangsu Tianyi Aviation Industry Co., LTD. The vehicle uses pure electric energy as the driving force, self-made chassis with upper and lower ladder body, movable side plate, diagonal lift device, platform assembly, front and rear legs, hydraulic system, electrical system and so on. The height of the flight ladder platform from the ground is 2400mm to 5900mm.


Drive motor Type Permanent magnet synchronous motor Energy storage device species Lithium iron phosphate
Rated power/speed kw/r/min 15/2400 type Energy type
Rated current A 195 Assembly system 26 Series 2 Parallel
Insulation class H
Protection class IP67
Rated voltage VAC 80 Assembly voltage V 83.72
drive
lectric
Machine control device
Input voltage VDC 65~95 Total energy stored kWh 46.38
Rated output voltage VAC 56.6 Unit nominal voltage V 3.22
Control mode Torque control Unit 3h rated capacity Ah 277
Total length mm 7770 Total width mm 2400
Total height mm 3650 wheelbase mm 3400
Wheel base (front/rear) mm 2000/ 2000 Maximum speed km/h 27.5
Activity platform travel mm 0~400 Curb weight kg 8200
Minimum ground clearance mm 180 Channel circle outer circle diameter mm 18200
Working height of platform mm 2400~ 5900 Height adjustment mode Upper and lower ladder body telescopic
Step depth mm 285 Number of steps up the ladder 12
Step width mm 1500 Number of steps down the ladder 15
Step height mm 192 Number of steps in the tailpiece ---
Maximum tilt Angle of ladder body (°) 39.5 Upper platform depth mm 3300
Temperature range ℃ -20~50 Upper platform width mm 1790
Driving range km 96 Endurance km+ times (large airport) 75+39
Endurance km+ times (medium airport) 75+41 Endurance km+ times (small airport) 77+43
