Self-propelled Baggage Tractor

Jiangsu Tianyi Aviation Industy Co., Ltd. is On the basis of Wuxi Tianyi Airport Special Equipment Co., Ltd., it was established in February 2011 with a registered capital of 88.66 million yuan. The company's annual output value exceeds 200 million yuan and covers an area of 120,000 square meters. Tianyi is working hard to bring green to civil airport, and is committed to becoming the leader of E-gse, and building safe, intelligent and green ground support equipment. Our baggage tractor is of good quality and we export a lot to foreign countries, we can ensure stable supply and long-term cooperation. Adpot ZY76A90-10003MD135FB-4P3SA lithium battery pack, power pressure 72V, capacity is 900Ah; 1238E-6521 speed setting controller; Schabmueller GMBH TSA300-270-003 towing motor rated towing weight 30T
Availability:
Product Description
Ac traction motor mode Ac motor Controller of Traction   motor rated voltage V 48-80
Rated power/ rotate speed 22/1000 Over-current protection A 550
Rated voltage V 50 speed adjustment mode Step-less adjustment
Rated current 340 battery type Lithium iron phosphate
insulation grade F Rated voltage V 72
Capacity Ah 900
Single voltage V 3.2
Single capacity Ah 75
Total length mm 3610 Total width mm 1400
Total height mm 2060 Wheelbase mm 1950
Wheelbase(front/rear) mm 1200/1200 Front hanger mm 870
Rear hanger mm 790 ramp angle(°) 23.5
Approach angle(°) 19 Departure angle(°) 21.5
Min. ground clearance  (mm) 150 Min. turning diameter mm 6550
Max. speed km/h 25 curb weight kg 4920
Load of front axle 1880 Load of rear axle 3040
Max. drawbar pull 29 Max. tractive tonnage 30000
Rated .drawbar pull 9 --- ---
