Driverless Luggage tractor

The traction bar is connected with the cargo flatbed truck, and the driving force generated by the body electric drive system is used to drive and pull the special equipment of the moving cargo flatbed truck. The driving type is rear drive, and the braking type is front disc and rear drum. The vehicle layout type is closed, rear-mounted cab (optional front-mounted), the front and rear windshield can be opened, the occupant is 2, the maximum speed is 30km/h, the maximum tractive force is 35kN, the rated traction weight is 35500kg, and the driving range is 360km on a single charge.

L4 Level Driverless Luggage tractor
Optical phased matrix radar
Long-range millimeter-wave radar
GNSS Differential Enhanced Positioning System
64-line mechanical lidar
Long-range millimeter-wave radar
Availability:
Product Description

L4 Level Driverless Luggage tractor

Optical phased matrix radar

Long-range millimeter-wave radar

GNSS Differential Enhanced Positioning System

64-line mechanical lidar

Long-range millimeter-wave radar


Vehicle parameter table

drive
           motor
Type Permanent magnet synchronous AC motor Driving motor controller Rated voltage    V 309
Rated power       KW 30 Overcurrent protection A 350
Rated voltage        V 309 Waterproofing class IP67
Rated current (1h operating system) A 135 Power cell Class type Lithium iron phosphate battery
Protection class IP67 Protection class IP68
Insulation class H Rated voltage   V 309.12
Energy stored  KWh 70.48
Total capacity  Ah 228
Total length  mm 3130 Total width    mm 1440
Total height  mm 1980 wheelbase   mm 1610
Angle of approach(°) 20 Departure Angle(°) 21
Front wheel pitch  mm 1270 Rear wheel pitch   mm 1215
Front overhang  mm 780 Rear overhang  mm 740
Minimum ground clearance  mm 145 Minimum turning radius   mm 3500
Maximum speed in no load    km/h 30 self-weight  kg 3750
Maximum traction    kN 35 Maximum traction mass   kg 35500
Rated traction  kN 12 Range on a single charge  km 360
