Driverless Passenger boarding

The platform on the passenger elevator is equipped with an operating device, which can operate the fine-tuning of the angle of the ladder body and the platform expansion and contraction, and the height of the tail ladder from the ground is 180mm during the normal operation, and the handrail is made of stainless steel, and the whole machine adopts the self-manufactured electric chassis, with variable frequency and stepless speed regulation. The main supporting parts are selected from famous brand products with high reliability, advanced technical performance and complete functions. The energy-saving performance of pure electric power is in line with the demand of green environmental protection; the product has beautiful appearance, wide lifting range, wide application, simple, safe, advanced design can meet the current use of all domestic aircraft models.
L4 Level Driverless Passenger boarding
64-line mechanical lidar
Proximity Blind Zone Detection LIDAR
ASD System

Availability:
Product Description

L4 Level Driverless Passenger boarding

64-line mechanical lidar

Proximity Blind Zone Detection LIDAR

ASD System


name parameter name Model number
Height range of passenger elevator 2400~5800mm Energy storage assembly L228C01
Platform size (L x W) 3300mm x 2810mm Energy storage unit CB230
Size and number of steps
       Sliding ladder (L x W x H)
285mm x 1500mm x 192mm, Grade 12 Driving motor HCDM030HP2
Fixed ladder (L x W x H) 285mm x 1500mm x 192mm, Grade 15 Drive motor controller HC30LKPIC-K21-V1-TY
Maximum slope Angle of ladder body 38.5° Oil pump motor HCDM007MG1
Minimum ground clearance 200 mm Oil pump motor pump controller HCDM007CL1
Channel circle outer circle diameter 18200 mm Hydraulic pump GHP2A-D-12-FG
wheelbase 3400 mm Lift cylinder JSTY5080KTE-0404000
Front/rear wheel base 2000 mm Telescopic cylinder JSTY5080KTE-0207100
Overall dimensions (L x W x H) 7770mm x 2400mm x 3650mm Supporting leg cylinder JSTY5080KTE-0101250
Total vehicle quality 6500kg chassis JSTY5080KTE-1000000
Rated bearing capacity (100 people) Axial axis 3000000-HY450Z
Load per step 225kg(3 persons) Drive shaft 2400000-HY455
Front axle load 3500kg(narrow platform), 3600 (Wide platform) tyre 215/75R17.5
Rear axle load 3000kg(without awning)
Maximum speed 30km/h
Minimum stable speed 0.5 km/h
endurance Small airports: 121km+61 times
Large airports: 124km+60 times
Medium airports: 124km+62 times

Driving motor power 60kw
Assembly voltage 347.76 V
Total energy stored Lithium Iron Phosphate Battery Pack, 60.16kwh
Temperature range

-35~65°C


Battery energy density 157.18 wh/kg
