JSTY5070GWS GSE Lavatory Service Truck For Airport realizes the effective control of the maximum driving speed with microcomputer program control, in order to avoid the safety hazards brought by speeding, and at the same time ensure the free action of the accelerator pedal within the speed limit.
Speed limit range: The system commonly used speed limit range is: 10 to 160 km/h Settings.
Product characteristics
(1) GPS positioning speed measurement;
(2) can intelligently configure the original vehicle speed signal;
(3) It has the function of forcing speed limit after overspeed;
(4) Speed limit buffer time can be freely set by the customer;
(5) Working voltage range DC12V ~ 28V;
(6) Working low power consumption: only 5w.
Technical parameter
(1) The applicable ambient temperature is -35℃ to 85℃;
(2) Apply to the road level 3 and above the level 3 standard;
(3) Speed limit range: 10-160 km/h;
(4) Speed limit deviation: ± 2km/h;
(5) Anti-vibration performance indicators: frequency 20-50HZ, acceleration 1g;
GSE Lavatory Service Truck For Airport configuration Two Main performance indicators:
Engine type: 4HK1-TCN2
Water tank volume (L) : 1400
Sewage tank volume (L) : 2360 (with vacuum pump) /2600 (without vacuum pump)
Water supply flow (L/min) :130
Water supply pressure (MPa) : 0.345
Maintenance weight (kg) : 4200
Overall dimensions (L × W × H) (mm) : 7330x2220x2400
Maximum speed (km/h) : 80
Other features optional: Minimum turning diameter mm: 14000; Optional: Vacuum pump
Chassis model: QL1080ZKARZY
Working platform lifting height (mm) : 550 ~ 2800
Engine emissions: Exhaust pollutants meet GB 17691-2005 phase III limit requirements, exhaust smoke meets GB 3847-2005 requirements
Circulation tank volume (L) : 240 (with vacuum pump) /0 (without vacuum pump)
Transmission model: MYY-6S
