Diesel / Motorized Belt Loader

TY-XC80 self-propelled convener-belt loader primarily consists of body, conveying rack, chassis power drive system, front and rear lifting mechanisms, hydraulic operating system, electrical system and other components.
Availability:
Product Description

Major Structure and Configuration

201904161330569881534


TY-XC80 self-propelled convener-belt loader primarily consists of body, conveying rack, chassis power drive system, front and rear lifting mechanisms, hydraulic operating system, electrical system and other components.

1.1 Body

1.2 Conveying Rack

1.3 Front and Rear Lifting Mechanisms

1.4 Power system


TX-XC80A Driving system:

Engine: Perkins 404D-22, EuoIII emisssion

Transmission:Graziano , PST2 auto hydrulic transmission.


TX-XC80B Driving system:

Engine: ISUZU ak-c240pkj-30 diesel enigne, EurIII emission


TX-XC80CDriving system:

Engine:Cummins QSF2.8(37KW@2500rpm)diesel enigne, ChinaIV emission

Transmission: Japan Y43280E, auto hydrulic transmission

1.5 Hydraulic Operating System


1.6 Electrical System and Safety Device

The system voltage is DC 12V.



1.7 Main configuration

No.

Item

Type

Brand

1

Chassis

Self-made

china

2

Cabin

left drive

china

3

Engine

C240-NBKEG-01-C3

Isuzu

4

Transmission

Y43280E

Japan

5

Front and rear axles

HY430

China

6

Gear pump

CBHZ-F25

China

7

Tire

225/70R15

China

8

Feed belt

700mm

USA

9

Hydraulic cylinder

D50/28-250

China

10

Hydraulic block

RPE3-063

ARGO

DSG-01-3C4

China

11

Conveyor motor

JS-250

EATON(USA)

12

Check valve

VUR380

Oleoweb(Italy)

CIT-06-04-50

China

13

Balance valve

PRE3-063

EATON(USA)

14

Magnetic ball valve

EDT6

Oleoweb(Italy)

15

Hydraulic steering gear

XCEL45

EATON(USA)

101S-1

China

16

Hose fitting


Parker

17

Relay

RH4B-UL

Japan

18

Relay socket

PTF14A-E

Japan

19

Button

YWIB-A1E10

Japan

20

Travel switch

WLNJ-30

Omron

21

Emergency switch

YW1B-V4E10R

Japan

22

Alarm lamp

FL-4871

Japan

23

Indicator lamp


Japan
